Parameter name

Unit

Parameter values

Rated dead weight

kg

2×2000

The number of passengers

人

2×24

Rated speed up

m/min

37.5

Raise the maximum speed

m

150

Electrical powerJC25%

kw

2×3×11

Hanging empty cage size

m

3×1.3×2.5

Hoists quality (with cab)

kg

1180

Festival quality standards

kg

160

Standard length of the section

m

1.508

Rated weight from boom

kg

200

Cage at the end of the largest size

m

3.84×3.3

Self-boom

kg

98.6

Hoisting cable diameter

mm

φ8

Electric Model

/

YZZ132M-4

Anti-dropping device safety

Model

/

SAJ30-1.2

Rated speed

m/s

1.2

Free high-end

m

7.5

Whole machine quality（150m）

kg

19600
